• SUBMARINE WATERPROOF, Magnetic Angle Sensor, Pulse Width Modulation Control
• REEFS LINK required for Programming (Optional)

Voltage: 6v-8.4v

All Metal Gears

CNC Aluminum Casing w/ Heat Sink

Bearing Type: 2BB

Temp Rate: -15C°~ 70C

Torque: 85oz @ 6.0v

95oz @ 7.4v

103oz @ 8.4v

Speed: .11sec @ 6.0v

.10sec @ 7.4v

.08sec @ 8.4v

Spline: 25T Standard

Dead Band Width: 2¦Ìs

Unload Current:

180mA @ 4.8V 200mA @ 6.0V 230mA @ 7.4V 260mA @ 8.4V

Load Current:

1200mA @ 4.8V 1400mA @ 6.0V 1500mA @ 7.4V 1800mA @ 8.4V

BEC Not Required, Recommended

for Max Perf.
